Overview
The 4K View Pro is a powerful real 4K video processor with a latency as low as 1 frame, which supports 4K×2K@60Hz video input and output. Hardware has been designed with a robust FPGA system architecture, high-performance Scalar core, and ultra-low latency. The 4K ViewPro allows multiple ultra HD real 4K×2K@60Hz input and output for scaling, switching, and signal conversion to provide a perfect image processing experience. The 4K View Pro can be widely used for high-end rental, stage control, fine pitch LED displays and broadcasting stations.
Specifications
| Model | 4K ViewPro |
|---|---|
| Inputs | 12G-SDI x2 (level A & B), HDMI 2.0, DP 1.2 |
| Max Input Resolution | 4K × 2K @ 60 Hz 4:2:2 10-bit |
| SDI Standards | ST-2082 (12G), ST-2081 (6G), ST-424 (3G), ST-292 (HD), SMPTE 259 (SD) |
| 12G-SDI Loop | Re-driven 12G-SDI loop-through |
| Best For | 4K video processing for LED walls — broadcast camera feeds, live production, fixed install |
Need help configuring the 4K ViewPro?
Our engineering team will help spec out inputs, outputs, and accessories for your project. Same-day shipping on stocked units from our Florida warehouse.
Talk to an Engineer
